ITW Dynatec SR Adhesive Supply Unit
System Specifications
System | SR05 | SR10 | SR22 | SR45 |
---|---|---|---|---|
Hopper Capacity | 5kg (10lbs) | 10kg (22lbs) | 22 kg (48 lbs) | 45 kg (100 lbs) |
Operating Temperature | 10 to 218°C (50 to 425°F) | 10 to 218°C (50 to 425°F) | 10 to 218°C (50 to 425°F) | 10 to 218°C (50 to 425°F) |
Melt Rate (per hour)* | 10 kg/hr (23 lb/hr) | 10 kg/hr (23 lb/hr) | 22 kg/h (50 lbs/h) | 23 kg/h (51 lbs/h) |
Melt Rate (per hour)* w/ Optional Grid | N/A | 15 kg/hr (34 lbs/hr) | 41 kg/h (91 lbs/h) | 45 kg/h (100 lbs/h) |
Pump Rate per minute* (Piston / 4.5cc Gear) | .91kg (2lb) / .38kg (.83lb) | .91kg (2lb) / .38kg (.83lb) | .91kg (2lb) / .38kg (.83lb) | .91kg (2lb) / .38kg (.83lb) |
Piston Pump Compression Ratios | 12:1 | 12:1 | 12:1 | 12:1 |
Gear Pumps Sizes | from 0,16 to 20 ccm/rev | from 0,16 to 20 ccm/rev | from 0,16 to 20 ccm/rev | from 0,16 to 20 ccm/rev |
Hose Output Zones | 2, 4, or 6 | 2, 4, or 6 | 2, 4 or 6 | 2, 4 or 6 |
Max Working Hydraulic Pressure | 68bar (1,000psi) | 68bar (1,000psi) | 68 bar (1,000 psi) | 68 bar (1,000 psi) |
Temperature Control Stability | ± 1°C (1°F) | ± 1°C (1°F) | ± 1°C (1°F) | ± 1°C (1°F) |
Electrical Service Standard 1 | 200- 240 VAC 1Phase 50/60 Hz 200-240 VAC 3Phase 50/60 Hz |
200-240 VAC 1Phase 50/60 Hz 200-240 VAC 3Phase 50/60 Hz |
200-240 VAC 1Phase 50/60 Hz 200-240 VAC 3Phase 50/60 Hz |
200-240 VAC 1Phase 50/60 Hz 200-240 VAC 3Phase 50/60 Hz |
Electrical Service Standard 2 | 240/400 VAC 3Phase Y 50/60 Hz | 240/400 VAC 3Phase Y 50/60 Hz | 240/400 VAC 3Phase Y 50/60 Hz | 240/400 VAC 3Phase Y 50/60 Hz |
Working Viscosity | 500 – 50,000cps | 500 – 50,000cps | 500 – 50,000cps | 500 – 50,000cps |
Dimensions
Dimensions | SR05 | SR10 | SR22 | SR45 |
---|---|---|---|---|
Height (H)† | 533 mm (20.96 in) | 661 mm (26 in) | 918 mm (36.1 in) | 1324 mm (52.1 in) |
Depth (D) | 427 mm (16.8 in) | 427 mm (16.8 in) | 456 mm (18 in) | 456 mm (18 in) |
Width (W) | 655 mm (25.79 in) | 655 mm (25.79 in) | 851 mm (33.5 in) | 851 mm (33.5 in) |
Weight (empty) | 59 kg (129 lbs) | 63 kg (138 lbs) | 80 kg (177 lb) | 90 kg (198 lbs) |
Accessories
Optional Accessories |
---|
Analog or digital pressure gauge |
Adhesive Low Level Sensor |
Tethered pendant controller display |
480 VAC transformer |
Drop-in heating grid (SR10, SR22 and SR45 only) |
Ethernet module |
FEATURES
- Intuitive, easy to read display is repositionable to front or side of unit and shows all system parameters at a glance.
- Consumes up to 20 % less energy and significantly less air than similar competitive units, reducing operating costs.
- New Nano ceramic hopper coating is 5 times more durable than competitive PTFE coatings to withstand wear.
- Replace modular electronics, filters and pumps easily with new simplified prodecures.
Melt On Demand
![melt-on-demand melt-on-demand](https://www.hotmeltunits.com/wp-content/uploads/2022/03/melt-on-demand.png)
MELT ON DEMAND
Adhesive degradation is recognized as the number one cause of downtime on hot melt equipment. To address this problem, ITW Dynatec has patented a “Melt‑On‑Demand” system. ITW Dynatec’s vertical, unheated hoppers only melt the amount of adhesive required by the application. Most of the hot melt adhesive in the hopper remains at a much lower temperature, perhaps even solid state. The added benefits of melting only the adhesive required are quicker start-ups, reduced energy costs, better viscosity control, and reduced fumes.
